Cable and Cord Grips

Mfr Part #	Quantity	Price	Series	Package	Product Status	Color	Material	Thread Size	Type	Operating Temperature	Conduit Hub Size	Panel Hole Size	Includes	Ingress Protection	Outside Cable Diameter (Max)	Outside Cable Diameter (Min)	Thread Length
M3243 FLEX LTCG PG-11 BLKW/3169 NUT Heyco Products Datasheet	3,338 In Stock	1 : $2.29 10 : $19.90 25 : $47.75 50 : $93.50 100 : $178.00 250 : $402.50 500 : $740.00 1,000 : $1,270.00 2,500 : $2,975.00 Box	Heyco®-Tite	Box	Active	Black	Polyamide (PA66), Nylon 6/6	PG11	Cable Grip	-40°C ~ 115°C	-	0.732" (18.6mm)	Locknut, Strain Relief	IP68 - Dust Tight, Waterproof	0.395" (10.03mm)	0.230" (5.84mm)	0.380" (9.65mm)
4609 EMC BRASS CGHT M16-80X5MMTHD Heyco Products Datasheet	49 In Stock	1 : $21.11 10 : $184.90 25 : $442.25 50 : $856.00 100 : $1,655.00 250 : $3,910.00 500 : $7,590.00 Box	Heyco®-Tite	Box	Active	Silver	Brass, Nickel Plated	M16x1.5	Cable Grip	-40°C ~ 100°C	-	0.630" (16.0mm)	-	IP68/IP69K - Dust Tight, Water Resistant, Waterproof	0.315" (8.00mm)	0.236" (6.00mm)	0.200" (5.08mm)
M3219 LTCG PG-16 BLACKW/3173 NUT Heyco Products Datasheet	488 In Stock	1 : $2.30 5 : $9.60 10 : $17.30 25 : $38.50 50 : $69.00 100 : $134.00 250 : $327.50 500 : $635.00 1,000 : $1,150.00 Box	Heyco®-Tite	Box	Active	Black	Polyamide (PA66), Nylon 6/6	PG16	Cable Grip	-40°C ~ 115°C	-	0.886" (22.5mm)	Locknut	IP68 - Dust Tight, Waterproof	0.545" (13.84mm)	0.260" (6.60mm)	0.440" (11.18mm)
M4524 LTCG 1-1/4 NPT BLACK-NO NUT Heyco Products Datasheet	43 In Stock	1 : $5.79 5 : $28.20 10 : $54.90 25 : $133.25 50 : $251.50 100 : $488.00 250 : $1,105.00 500 : $2,135.00 1,000 : $4,110.00 Box	Heyco®-Tite	Box	Active	Black	Polyamide (PA66), Nylon 6/6	1/4" NPT	Cable Grip	-40°C ~ 115°C	-	1.680" (42.7mm)	-	IP68 - Dust Tight, Waterproof	1.260" (32.00mm)	0.875" (22.23mm)	0.780" (19.81mm)
4616 EMC BRASS CG M10-60 Heyco Products Datasheet	40 In Stock	1 : $15.40 10 : $136.50 25 : $328.00 50 : $630.00 100 : $1,190.00 250 : $2,712.50 500 : $5,075.00 1,000 : $9,310.00 Box	Heyco®-Tite	Box	Active	Silver	Brass, Nickel Plated	M10x1.5	Cable Grip	-40°C ~ 100°C	-	0.394" (10.0mm)	-	IP68/IP69K - Dust Tight, Water Resistant, Waterproof	0.236" (6.00mm)	0.157" (4.00mm)	0.390" (9.91mm)
M4520 RLTCG LL 1/2 NPT BLACK-NO NUT Heyco Products Datasheet	3,029 In Stock	1 : $1.79 10 : $15.60 25 : $37.50 50 : $73.00 100 : $140.00 250 : $315.00 500 : $580.00 1,000 : $1,000.00 2,500 : $2,325.00 Box	Heyco®-Tite	Box	Active	Black	Polyamide (PA66), Nylon 6/6	1/2" NPT	Cable Grip	-40°C ~ 115°C	-	0.875" (22.2mm), 7/8"	-	IP68 - Dust Tight, Waterproof	0.400" (10.16mm)	0.180" (4.57mm)	0.440" (11.18mm)
M3231 LTCG 1/2 NPT BLACK-NO NUT Heyco Products Datasheet	3,116 In Stock	1 : $1.71 5 : $7.15 10 : $12.80 25 : $28.50 50 : $51.50 100 : $100.00 250 : $242.50 500 : $470.00 1,000 : $860.00 Box	Heyco®-Tite	Box	Active	Black	Polyamide (PA66), Nylon 6/6	1/2" NPT	Cable Grip	-40°C ~ 115°C	-	0.875" (22.2mm), 7/8"	-	IP68 - Dust Tight, Waterproof	0.450" (11.43mm)	0.170" (4.32mm)	0.610" (15.49mm)
3454 RLTF 21 BLACK W/3175 NUT Heyco Products Datasheet	559 In Stock	1 : $2.69 10 : $23.40 25 : $56.00 50 : $109.50 100 : $209.00 250 : $472.50 500 : $870.00 1,000 : $1,490.00 2,500 : $3,475.00 Box		Box	Active	Black	Polyamide (PA66), Nylon 6/6	PG21	Cable Grip	-40°C ~ 115°C	-	1.114" (28.3mm)	Locknut	IP68 - Dust Tight, Waterproof	0.485" (12.32mm)	0.250" (6.35mm)	0.520" (13.21mm)
M5240 AL CG NPT 1/2-500-90 Heyco Products Datasheet	3 In Stock	1 : $15.09 10 : $133.70 25 : $321.50 50 : $617.00 100 : $1,166.00 250 : $2,657.50 500 : $4,970.00 1,000 : $9,120.00 Box	Heyco®-Tite	Box	Active	Silver	Aluminum	1/2" NPT	Cable Grip - 90°	-40°C ~ 121°C	-	0.880" (22.4mm)	-	IP67 - Dust Tight, Waterproof	0.500" (12.70mm)	0.438" (11.13mm)	0.560" (14.22mm)
M4344 LTCG M25 BLACKW/M9136 NUT Heyco Products Datasheet	910 In Stock	1 : $2.15 5 : $10.20 10 : $19.90 25 : $48.25 50 : $94.00 100 : $177.00 250 : $415.00 500 : $805.00 1,000 : $1,560.00 Box	Heyco®-Tite	Box	Active	Black	Polyamide (PA66), Nylon 6/6	M25	Cable Grip	-40°C ~ 115°C	-	0.984" (25.0mm)	Locknut	IP68 - Dust Tight, Waterproof	0.705" (17.91mm)	0.435" (11.05mm)	0.520" (13.21mm)
