Mfr Part #	Quantity	Price	Series	Package	Product Status	Package / Case	Mounting Type	Voltage - Input	Programmable Type	Number of Macrocells	Supplier Device Package	Speed	DigiKey Programmable
GAL20V8QS-10LNC EE PLD, 10NS, PAL-TYPE National Semiconductor Datasheet	1,220 Marketplace	139 : $301.63 Bulk	GAL®20V8QS	Bulk	Active	24-DIP (0.600", 15.24mm)	Through Hole	4.75V ~ 5.25V	EE PLD	8	24-DIP	10 ns	Not Verified
GAL20V8QS-10LVI EE PLD, 10NS, PAL-TYPE PQCC28 National Semiconductor Datasheet	1,995 Marketplace	143 : $300.30 Bulk	GAL®20V8QS	Bulk	Active	28-LCC (J-Lead)	Surface Mount	4.5V ~ 5.5V	EE PLD	8	28-PLCC (11.43x11.43)	10 ns	Not Verified
GAL20V8A-15LVI EE PLD, 15NS, PAL-TYPE PQCC28 National Semiconductor Datasheet	1,083 Marketplace	207 : $302.22 Bulk	GAL®20V8	Bulk	Active	28-LCC (J-Lead)	Surface Mount	4.5V ~ 5.5V	PAL	8	28-PLCC (11.43x11.43)	15 ns	Not Verified
GAL20V8A-15LNC EE PLD, 15NS, PAL-TYPE National Semiconductor Datasheet	3,171 Marketplace	160 : $300.80 Bulk	GAL®20V8	Bulk	Active	24-DIP (0.600", 15.24mm)	Through Hole	4.75V ~ 5.25V	PAL	8	24-PDIP	15 ns	Not Verified
GAL22V10-20LVI IC PLD 10MC 10NS 28PLCC National Semiconductor Datasheet	973 Marketplace	49 : $300.86 Bulk	GAL®22V10	Bulk	Active	28-LCC (J-Lead)	Surface Mount	-	EE PLD	10	28-PLCC (11.43x11.43)	10 ns	Not Verified
GAL20V8QS-25LVC IC CPLD 8MC 25NS 28PLCC National Semiconductor Datasheet	1,327 Marketplace	249 : $301.29 Bulk	GAL®20V8QS	Bulk	Active	28-LCC (J-Lead)	Surface Mount	-	EE PLD	8	28-PLCC (11.43x11.43)	-	Not Verified
GAL20V8QS-10LVC EE PLD, 10NS, PAL-TYPE PQCC28 National Semiconductor Datasheet	2,674 Marketplace	139 : $301.63 Bulk	GAL®20V8QS	Bulk	Active	28-LCC (J-Lead)	Surface Mount	4.75V ~ 5.25V	EE PLD	8	28-PLCC (11.43x11.43)	10 ns	Not Verified
GAL22CV10-10LNC IC CPLD 10MC 10NS 24DIP National Semiconductor Datasheet	11,604 Marketplace	67 : $302.17 Bulk	GAL®22CV10	Bulk	Active	24-DIP (0.300", 7.62mm)	Through Hole	-	EE PLD	10	24-DIP	-	Not Verified
GAL20V8-25QNC EE PLD, 25NS, PAL-TYPE National Semiconductor Datasheet	2,234 Marketplace	185 : $299.70 Bulk	GAL®20V8	Bulk	Active	-	-	-	EE PLD	-	-	25 ns	Not Verified
GAL20V8QS-25QVI IC CPLD 8MC 25NS 28PLCC National Semiconductor Datasheet	3,007 Marketplace	167 : $300.60 Bulk	GAL®20V8QS	Bulk	Active	28-LCC (J-Lead)	Surface Mount	-	EE PLD	8	28-PLCC (11.43x11.43)	-	Not Verified
