Mfr Part #	Quantity	Price	Series	Package	Product Status	Tolerance	Features	Package / Case	Size / Dimension	Mounting Type	Type	Operating Temperature	Lead Spacing	Ratings	ESR (Equivalent Series Resistance)	Lifetime @ Temp.	Manufacturer Size Code	Height - Seated (Max)	Capacitance	Voltage - Rated
TCTOAS0J107M8R-ZW1 CAP TANT POLY 100UF 6.3V 1206 ROHM Semiconductor Datasheet	10,796 In Stock	3,000 : $1,410.00 6,000 : $2,700.00 9,000 : $3,960.00 15,000 : $6,450.00 Tape & Reel (TR)	TCTO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1206 (3216 Metric)	0.126" L x 0.063" W (3.20mm x 1.60mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	70mOhm @ 100kHz	-	AS	0.039" (1.00mm)	100 µF	6.3 V
TCTOAS1A476M8R-ZB1 CAP TANT POLY 47UF 10V 1206 ROHM Semiconductor Datasheet	10,138 In Stock	3,000 : $1,020.00 6,000 : $1,980.00 9,000 : $2,790.00 15,000 : $4,650.00 30,000 : $9,000.00 Tape & Reel (TR)	TCTO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1206 (3216 Metric)	0.126" L x 0.063" W (3.20mm x 1.60mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	100mOhm @ 100kHz	-	AS	0.039" (1.00mm)	47 µF	10 V
TCTOBL1V685M8R-ZF1 CAP TANT POLY 6.8UF 35V 1411 ROHM Semiconductor Datasheet	3,928 In Stock	3,000 : $1,560.00 6,000 : $3,000.00 9,000 : $4,320.00 15,000 : $7,050.00 Tape & Reel (TR)	TCTO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	150mOhm @ 100kHz	-	BL	0.047" (1.20mm)	6.8 µF	35 V
TCTOBL0J157M8R-ZN1 CAP TANT POLY 150UF 6.3V 1411 ROHM Semiconductor Datasheet	5,270 In Stock	3,000 : $1,650.00 6,000 : $3,180.00 9,000 : $4,590.00 15,000 : $7,500.00 Tape & Reel (TR)	TCTO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	35mOhm @ 100kHz	-	BL	0.047" (1.20mm)	150 µF	6.3 V
TCOB0J227M8R-EN1 CAP TANT POLY 220UF 6.3V 1411 ROHM Semiconductor Datasheet	3,396 In Stock	2,000 : $940.00 4,000 : $1,800.00 10,000 : $4,400.00 14,000 : $6,020.00 Tape & Reel (TR)	TCO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	35mOhm @ 100kHz	-	B	0.083" (2.10mm)	220 µF	6.3 V
TCTOA0J107M8R-ZS1 CAP TANT POLY 100UF 6.3V 1206 ROHM Semiconductor Datasheet	4,000 In Stock	2,000 : $600.00 4,000 : $1,160.00 10,000 : $2,800.00 14,000 : $3,780.00 Tape & Reel (TR)	TCTO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1206 (3216 Metric)	0.126" L x 0.063" W (3.20mm x 1.60mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	45mOhm @ 100kHz	-	A	0.071" (1.80mm)	100 µF	6.3 V
TCOB0J107M8R-ES1 CAP TANT POLY 100UF 6.3V 1411 ROHM Semiconductor Datasheet	3,605 In Stock	2,000 : $660.00 4,000 : $1,280.00 10,000 : $3,100.00 14,000 : $4,200.00 Tape & Reel (TR)	TCO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	1411 (3528 Metric)	0.138" L x 0.110" W (3.50mm x 2.80mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	45mOhm @ 100kHz	-	B	0.083" (2.10mm)	100 µF	6.3 V
TCSOPS0J476M8R-ZF1 CAP TANT POLY 47UF 6.3V 0805 ROHM Semiconductor Datasheet	17,900 In Stock	3,000 : $660.00 6,000 : $1,200.00 9,000 : $1,800.00 15,000 : $2,850.00 30,000 : $5,700.00 Tape & Reel (TR)	TCSO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	150mOhm @ 100kHz	-	PS	0.035" (0.90mm)	47 µF	6.3 V
TCSOPL1E475M8R-ZT1 CAP TANT POLY 4.7UF 25V 0805 ROHM Semiconductor Datasheet	2,848 In Stock	3,000 : $840.00 6,000 : $1,560.00 9,000 : $2,250.00 15,000 : $3,750.00 30,000 : $7,200.00 Tape & Reel (TR)	TCSO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	500mOhm @ 100kHz	-	PL	0.039" (1.00mm)	4.7 µF	25 V
TCSOM0J476M8R-ZM1 CAP TANT POLY 47UF 6.3V 0603 ROHM Semiconductor Datasheet	0 In Stock	3,000 : $630.00 6,000 : $1,200.00 9,000 : $1,710.00 15,000 : $2,850.00 30,000 : $5,400.00 Tape & Reel (TR)	TCSO	Tape & Reel (TR) Cut Tape (CT)	Active	±20%	General Purpose	0603 (1608 Metric)	0.063" L x 0.033" W (1.60mm x 0.85mm)	Surface Mount	Molded	-55°C ~ 105°C	-	-	300mOhm @ 100kHz	-	M	0.039" (1.00mm)	47 µF	6.3 V
