0393560000

Part Number
0393560000
Manufacturer Weidmuller
Other Part Numbers
0393560000-ND
0393560000-NDR
TOP 1.5GS/4/90 7.62 OR
TOP4GS7.62/90/4
Description TERM BLK 4P SIDE ENT 7.62MM PCB
Detailed Description 4 Position Wire to Board Terminal Block Horizontal with Board 0.300" (7.62mm) Through Hole
Datasheet Datasheet

Product Attributes

Category
Manufacturer Weidmuller
Series
Omnimate TOP1.5GS
Packaging
Bulk
Part Status Obsolete
Features Interlocking (Side)
Color Orange
Mounting Type Through Hole
Wire Gauge 14-26 AWG
Pitch 0.300" (7.62mm)
Mating Orientation Horizontal with Board
Positions Per Level 4
Wire Termination Screw - TOP Clamp
Current 10 A
Number of Levels 1
Voltage 300 V

Documents & Media

RESOURCE TYPE LINK
Datasheets 0393560000
Datasheets End of Life 21/MAR/2022

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8536.90.4000
Moisture Sensitivity Level (MSL) Not Applicable
REACH Status REACH Unaffected
RoHS Status RoHS Compliant

Obsolete

This product is no longer manufactured.
