Category | ||
---|---|---|
Manufacturer | HARTING | |
Series | Han® M23 Signal | |
Packaging | Bulk | |
Part Status | Active | |
Contact Finish | Gold | |
Contact Termination | Crimp | |
Type | Signal, Machined | |
Contact Type | Socket | |
Contact Size | 1.5mm | |
Wire Gauge or Range - AWG | 17-20 AWG | |
Wire Gauge or Range - mm² | 0.56 ~ 1.0mm² | |
Contact Material | Copper Alloy |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | 09151006212 | |
Datasheets | 09151006212 Drawing |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8536.90.4000 | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
REACH Status | REACH Unaffected | |
RoHS Status | ROHS3 Compliant |
QUANTITY | UNIT PRICE | EXT PRICE |
---|---|---|
1 | $4.09 | $4.09 |
10 | $3.71 | $37.10 |
25 | $3.52 | $88.00 |
50 | $3.44 | $172.00 |
100 | $3.27 | $327.00 |
250 | $2.86 | $715.00 |
500 | $2.78 | $1,390.00 |
1,000 | $2.37 | $2,370.00 |
2,500 | $2.21 | $5,525.00 |
