117-93-652-41-005000 _ IC Sockets_Sockets for ICs, Transistors_Connectors, Interconnects

Part Number	117-93-652-41-005000
Manufacturer	Mill-Max
Other Part Numbers	ED22526-ND ED22526 117-93-652-41-005 1179365241005000
Description	CONN IC DIP SOCKET 52POS GOLD
Detailed Description	52 (2 x 26) Pos DIP, 0.6" (15.24mm) Row Spacing Socket Gold Through Hole
Manufacturer Standard Lead Time	2 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Sockets for ICs, Transistors IC Sockets
Manufacturer		Mill-Max
Series		117
Packaging		Tube
Part Status		Active
Features		Open Frame
Mounting Type		Through Hole
Type		DIP, 0.6" (15.24mm) Row Spacing
Operating Temperature		-55°C ~ 125°C
Number of Positions or Pins (Grid)		52 (2 x 26)
Termination		Solder
Material Flammability Rating		UL94 V-0
Housing Material		Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
Pitch - Mating		0.070" (1.78mm)
Contact Finish - Mating		Gold
Contact Finish Thickness - Mating		30.0µin (0.76µm)
Contact Material - Mating		Beryllium Copper
Pitch - Post		0.070" (1.78mm)
Contact Finish - Post		Tin-Lead
Contact Finish Thickness - Post		200.0µin (5.08µm)
Contact Material - Post		Brass Alloy
Termination Post Length		0.125" (3.18mm)
Current Rating (Amps)		3 A

RESOURCE TYPE		LINK
Datasheets		117 Series Side

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS non-compliant
