145C

145C

Part Number	145C
Manufacturer	Hammond Manufacturing
Other Part Numbers	HM3234-ND HM3234 145C-ND 3937-145C
Description	AUDIO XFMR 50K / 1.5KCT CHAS MNT
Detailed Description	50k Impedance Primary Ohms 1.5kCT Impedance Secondary Ohms Audio Transformer 150Hz ~ 15kHz Chassis Mount
Manufacturer Standard Lead Time	4 weeks
Datasheet	Datasheet

Product Attributes

Category		Transformers Audio Transformers
Manufacturer		Hammond Manufacturing
Series		145
Packaging		Bulk
Part Status		Active
Size / Dimension		1.630" L x 0.880" W (41.40mm x 22.35mm)
Mounting Type		Chassis Mount
Termination Style		Wire Leads
Transformer Type		Economical Open Type
Frequency Range		150Hz ~ 15kHz
Height - Seated (Max)		0.810" (20.57mm)
Impedance - Primary (Ohms)		50k
Impedance - Secondary (Ohms)		1.5kCT
DC Resistance (DCR) - Primary		2.4kOhm
DC Resistance (DCR) - Secondary		52Ohm
Frequency Response		±1dB
Power Level		50mW

Documents & Media

RESOURCE TYPE		LINK
Datasheets		Hammond REACH

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.31.4035
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

In Stock: 2

Can ship immediately.
