146F

146F

Part Number	146F
Manufacturer	Hammond Manufacturing
Other Part Numbers	HM3247-ND 146F-ND HM3247 3937-146F
Description	AUDIO XFMR 250CT / 3.2 CHAS MNT
Detailed Description	250CT Impedance Primary Ohms 3.2 Impedance Secondary Ohms Audio Transformer 150Hz ~ 15kHz Chassis Mount
Manufacturer Standard Lead Time	4 weeks
Datasheet	Datasheet

Product Attributes

Category		Transformers Audio Transformers
Manufacturer		Hammond Manufacturing
Series		146
Packaging		Bulk
Part Status		Active
Size / Dimension		1.630" L x 0.880" W (41.40mm x 22.35mm)
Mounting Type		Chassis Mount
Termination Style		Wire Leads
Transformer Type		Economical Open Type
Frequency Range		150Hz ~ 15kHz
Height - Seated (Max)		0.810" (20.57mm)
Impedance - Primary (Ohms)		250CT
Impedance - Secondary (Ohms)		3.2
DC Resistance (DCR) - Primary		11Ohm
DC Resistance (DCR) - Secondary		300mOhm
Frequency Response		±1dB
Power Level		700mW

Documents & Media

RESOURCE TYPE		LINK
Datasheets		Hammond REACH

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.31.4035
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

In Stock: 12

Can ship immediately.
