Part Number | 1611950000 |
---|---|
Manufacturer | Weidmuller |
Other Part Numbers | 1611950000-ND 1611950000-NDR STVS2SS 2266-1905100000 |
Description | TERM BLOCK PLUG 2POS STR 7MM |
Detailed Description | 2 Position Terminal Block Plug, Blade Pins 0.276" (7.00mm) 180° Free Hanging (In-Line) |
Category | ||
---|---|---|
Manufacturer | Weidmuller | |
Series | Powermate STV | |
Packaging | Bulk | |
Part Status | Obsolete | |
Features | Mating Flange | |
Color | Gray | |
Mounting Type | Free Hanging (In-Line) | |
Number of Positions | 2 | |
Pitch | 0.276" (7.00mm) | |
Screw Size | M3 | |
Type | Plug, Blade Pins | |
Operating Temperature | -50°C ~ 100°C | |
Termination Style | Screw - Clamping Yoke (Tension Sleeve) | |
Ingress Protection | IP20 | |
Material Flammability Rating | UL94 V-0 | |
Current - IEC | 32A | |
Number of Levels | 1 | |
Wire Gauge or Range - AWG | 12-22 AWG | |
Wire Gauge or Range - mm² | 0.5-4mm² | |
Positions Per Level | 2 | |
Contact Material | Copper Alloy | |
Plug Wire Entry | 180° | |
Housing Material | Thermoplastic, Wemid | |
Torque - Screw | 0.5-0.6 Nm (4.4-5.3 Lb-In) | |
Contact Mating Finish | Silver | |
Wire Strip Length | 9mm | |
Insulation Height | 0.843" (21.41mm) | |
Current - UL | 25 A | |
Voltage - IEC | 1 kV | |
Voltage - UL | 600 V |
RESOURCE TYPE | LINK |
---|
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8536.90.4000 | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
REACH Status | REACH Unaffected | |
RoHS Status | RoHS Compliant |
