1645180000 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	1645180000
Manufacturer	Weidmuller
Other Part Numbers	1645180000-ND 2266-1628360000 SLS 5.08/20/180B SN OR BX SLS 5.08/20 B OG 1645180000-NDR
Description	TERM BLOCK PLUG 20POS STR 5.08MM
Detailed Description	20 Position Terminal Block Plug, Male Pins 0.200" (5.08mm) 180° Free Hanging (In-Line)
Manufacturer Standard Lead Time	27 weeks

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		Weidmuller
Series		Omnimate SL
Packaging		Bulk
Part Status		Active
Color		Orange
Mounting Type		Free Hanging (In-Line)
Number of Positions		20
Pitch		0.200" (5.08mm)
Screw Size		M2.5
Type		Plug, Male Pins
Operating Temperature		-50°C ~ 100°C
Termination Style		Screw - Clamping Yoke (Tension Sleeve)
Material Flammability Rating		UL94 V-0
Current - IEC		21.5A
Number of Levels		1
Wire Gauge or Range - AWG		12-26 AWG
Wire Gauge or Range - mm²		0.2-2.5mm²
Positions Per Level		20
Contact Material		Copper Alloy
Plug Wire Entry		180°
Housing Material		Polybutylene Terephthalate (PBT)
Torque - Screw		0.4-0.5 Nm (3.5-4.4 Lb-In)
Contact Mating Finish		Tin
Wire Strip Length		7mm
Insulation Height		0.598" (15.19mm)
Current - UL		14 A
Voltage - IEC		400 V
Voltage - UL		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
