1645800000 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	1645800000
Manufacturer	Weidmuller
Other Part Numbers	1645800000-ND 1645800000-NDR SLS 5.08/17 TB BK
Description	TERM BLOCK PLUG 17POS STR 5.08MM
Detailed Description	17 Position Terminal Block Plug, Male Pins 0.200" (5.08mm) 180° Free Hanging (In-Line)

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		Weidmuller
Series		Omnimate SL
Packaging		Bulk
Part Status		Obsolete
Features		Rail Mount Foot
Color		Black
Mounting Type		Free Hanging (In-Line)
Number of Positions		17
Pitch		0.200" (5.08mm)
Screw Size		M2.5
Type		Plug, Male Pins
Operating Temperature		-20°C ~ 100°C
Termination Style		Screw - Clamping Yoke (Tension Sleeve)
Material Flammability Rating		UL94 V-0
Current - IEC		12A
Number of Levels		1
Wire Gauge or Range - AWG		12-28 AWG
Wire Gauge or Range - mm²		2.5mm²
Positions Per Level		17
Contact Material		Copper Alloy
Plug Wire Entry		180°
Housing Material		Polybutylene Terephthalate (PBT)
Torque - Screw		0.4-0.5 Nm (3.5-4.4 Lb-In)
Contact Mating Finish		Tin
Wire Strip Length		7mm
Insulation Height		0.646" (16.40mm)
Current - UL		15 A
Voltage - IEC		250 V
Voltage - UL		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected

This product is no longer manufactured.
