1697280000 _ Wire to Board_Terminal Blocks_Connectors, Interconnects

Part Number	1697280000
Manufacturer	Weidmuller
Other Part Numbers	1697280000-ND LP/7.62/135/2BK 1697280000-NDR LPP 7.62/02/135 4.5SN BK BX 2266-1862850000TR
Description	TERM BLOCK 2POS 45DEG 7.62MM PCB
Detailed Description	2 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.300" (7.62mm) Through Hole
Manufacturer Standard Lead Time	12 weeks

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		Weidmuller
Series		Omnimate LP
Packaging		Bulk
Part Status		Active
Features		Interlocking (Side)
Color		Black
Mounting Type		Through Hole
Wire Gauge		12-26 AWG
Pitch		0.300" (7.62mm)
Operating Temperature		-20°C ~ 100°C
Mating Orientation		45° (135°) Angle with Board
Positions Per Level		2
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Material - Plating		Copper Alloy - Tin Plated
Torque - Screw		0.5-0.6 Nm (4.4-5.3 Lb-In)
Screw Thread		M3
Wire Termination		Screw - Clamping Yoke, Tension Sleeve
Current		15 A
Number of Levels		1
Voltage		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
