1762032001 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	1762032001
Manufacturer	Weidmuller
Other Part Numbers	1762032001-ND SL-SMT3.50/05/90F 1.5SN BK BX 1762032001-NDR SL SMT 3.5/90/5 F BK 2266-1869900000
Description	TERM BLOCK HDR 5POS 90DEG 3.5MM
Detailed Description	5 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138" (3.50mm) 90°, Right Angle Through Hole
Manufacturer Standard Lead Time	27 weeks

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		Weidmuller
Series		Omnimate SL
Packaging		Bulk
Part Status		Active
Features		Mating and Mounting Flange
Color		Black
Mounting Type		Through Hole
Number of Positions		5
Pitch		0.138" (3.50mm)
Type		Header, Male Pins, Shrouded (4 Side)
Operating Temperature		-20°C ~ 100°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Current - IEC		13A
Number of Levels		1
Positions Per Level		5
Contact Material		Copper Alloy
Header Orientation		90°, Right Angle
Housing Material		Liquid Crystal Polymer (LCP), Halogen Free
Contact Mating Finish		Tin
Contact Tail Length		0.059" (1.50mm)
Insulation Height		0.295" (7.50mm)
Current - UL		10 A
Voltage - IEC		125 V
Voltage - UL		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
