1785940000 _ Wire to Board_Terminal Blocks_Connectors, Interconnects

Part Number	1785940000
Manufacturer	Weidmuller
Other Part Numbers	1785940000-ND 1785940000-NDR
Description	TERM BLK 4POS TOP ENT 5.08MM PCB
Detailed Description	4 Position Wire to Board Terminal Block Vertical with Board 0.200" (5.08mm) Through Hole

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		Weidmuller
Series		Omnimate TOP1.5GS
Packaging		Bulk
Part Status		Obsolete
Color		Black
Mounting Type		Through Hole
Wire Gauge		14-22 AWG
Pitch		0.200" (5.08mm)
Operating Temperature		-20°C ~ 100°C
Mating Orientation		Vertical with Board
Positions Per Level		4
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Material - Plating		Brass - Tin Plated
Torque - Screw		0.4-0.5 Nm (3.5-4.4 Lb-In)
Screw Thread		M2.5
Wire Termination		Screw - TOP Clamp
Current		10 A
Number of Levels		1
Voltage		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected

This product is no longer manufactured.
