1837297 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	1837297
Manufacturer	Phoenix Contact
Other Part Numbers	1837297-ND
Description	CCVA 2,5/ 6-G P20 THR R56
Detailed Description	6 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.197" (5.00mm) Vertical Through Hole
Manufacturer Standard Lead Time	6 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		Phoenix Contact
Series		COMBICON CCVA
Packaging		Tape & Reel (TR)
Part Status		Active
Color		Black
Mounting Type		Through Hole
Number of Positions		6
Pitch		0.197" (5.00mm)
Type		Header, Male Pins, Shrouded (4 Side)
Operating Temperature		-40°C ~ 100°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Current - IEC		12A
Number of Levels		1
Positions Per Level		6
Contact Material		Copper Alloy
Header Orientation		Vertical
Housing Material		Liquid Crystal Polymer (LCP)
Contact Mating Finish		Tin
Contact Tail Length		0.079" (2.00mm)
Insulation Height		0.472" (12.00mm)
Current - UL		16 A
Voltage - IEC		320 V
Voltage - UL		300 V

RESOURCE TYPE		LINK
Datasheets		1837297

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		RoHS Compliant
