224558-E _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	224558-E
Manufacturer	TE Connectivity ERNI
Other Part Numbers	2684-224558-ETR-ND 2684-224558-ECT-ND 2684-224558-EDKR-ND 2684-224558TR 2684-224558-ECT 2684-224558CT-ND 2684-224558CT 2684-224558-ETR 2684-224558DKR 2684-224558TR-ND 2684-224558DKR-ND 224558 2684-224558-EDKR
Description	50-PIN, VERTICAL, SMT/THR
Detailed Description	Connector Header Surface Mount, Through Hole 50 position 0.039" (1.00mm)
Manufacturer Standard Lead Time	61 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		TE Connectivity ERNI
Series		MICROSPEED
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Features		Board Guide, Pick and Place
Connector Type		Header
Current Rating (Amps)		1A
Mounting Type		Surface Mount, Through Hole
Number of Positions		50
Number of Rows		2
Style		Board to Cable/Wire
Operating Temperature		-55°C ~ 125°C
Contact Type		Male Pin
Fastening Type		Latch Holder
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Copper Alloy
Insulation Color		Black
Pitch - Mating		0.039" (1.00mm)
Contact Finish - Mating		Gold
Contact Finish - Post		Tin
Contact Finish Thickness - Post		157.5µin (4.00µm)
Contact Shape		Square
Contact Length - Post		0.047" (1.20mm)
Insulation Height		0.228" (5.80mm)
Shrouding		Shrouded - 4 Wall
Insulation Material		Liquid Crystal Polymer (LCP)
Row Spacing - Mating		0.059" (1.50mm)
Contact Length - Mating		0.114" (2.90mm)

RESOURCE TYPE		LINK
Datasheets		PN Change 26/JAN/2023

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant

Can ship immediately.
