231-110/031-000 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	231-110/031-000
Manufacturer	WAGO
Other Part Numbers	2946-231-110/031-000-ND 51116852 231110/031000 2943-231-110/031-000 2946-231-110/031-000 0231-110/031-000 2943-231-110/031-000-ND 0231110/031000 0231-0110/0031-0000
Description	1-CONDUCTOR FEMALE PLUG; CLAMPIN
Detailed Description	10 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 180° Free Hanging (In-Line)
Manufacturer Standard Lead Time	12 weeks

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		WAGO
Series		MCSMIDI Classic
Packaging		Box
Part Status		Active
Features		Mounting Flange, Retention Latches (Non-Wire Side)
Color		Gray
Mounting Type		Free Hanging (In-Line)
Number of Positions		10
Pitch		0.197" (5.00mm)
Type		Plug, Female Sockets
Operating Temperature		-60°C ~ 85°C
Termination Style		Screwless - Leg Spring, Push-In Spring
Current - IEC		16A
Number of Levels		1
Wire Gauge or Range - AWG		12-28 AWG
Wire Gauge or Range - mm²		0.08-2.5mm²
Positions Per Level		10
Plug Wire Entry		180°
Contact Mating Finish		Tin
Current - UL		15 A
Voltage - IEC		630 V
Voltage - UL		600 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
RoHS Status		ROHS3 Compliant
