257-754 _ Wire to Board_Terminal Blocks_Connectors, Interconnects_

+86-0755-8325-4547

257-754

257-754

Part Number	257-754
Manufacturer	WAGO
Other Part Numbers	2946-257-754-ND 0257-754 0257754 2943-257-754 257754 2943-257-754-ND 0257-0754 51123422 2946-257-754
Description	STACKABLE PCB TERMINAL BLOCK; PU
Detailed Description	1 Position Wire to Board Terminal Block Horizontal with Board Through Hole
Manufacturer Standard Lead Time	12 weeks

Product Attributes

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		WAGO
Series		257
Packaging		Box
Part Status		Active
Features		Push Button Actuated
Color		Blue
Mounting Type		Through Hole
Wire Gauge		12-28 AWG
Operating Temperature		-60°C ~ 105°C
Mating Orientation		Horizontal with Board
Positions Per Level		1
Housing Material		Polyamide (PA66), Nylon 6/6
Contact Material - Plating		Electrolytic Copper - Tin Plated
Clamp Material - Plating		Steel - Nickel Plated
Wire Termination		Screwless - Push Button Clamp
Current		15 A
Number of Levels		1
Voltage		300 V

Documents & Media

RESOURCE TYPE		LINK

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
