374719-E _ Headers, Receptacles, Female Sockets_Rectangular Connectors_Connectors, Interconnects

Part Number	374719-E
Manufacturer	TE Connectivity ERNI
Other Part Numbers	2684-374719-ETR-ND 2684-374719-ECT-ND 2684-374719-EDKR-ND 2684-374719-ECT 2684-374719DKR 2684-374719TR-ND 2684-374719-ETR 2684-374719-EDKR 374719 2684-374719CT 2684-374719TR 2684-374719DKR-ND 2684-374719CT-ND
Description	50-PIN, RIGHT ANGLE, SMT/THR
Detailed Description	50 Position Receptacle Connector 0.039" (1.00mm) Surface Mount, Right Angle; Through Hole Gold
Manufacturer Standard Lead Time	29 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Receptacles, Female Sockets
Manufacturer		TE Connectivity ERNI
Series		MICROSPEED
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Features		Board Guide
Connector Type		Receptacle
Current Rating (Amps)		1A
Mounting Type		Surface Mount, Right Angle; Through Hole
Number of Positions		50
Style		Board to Board
Operating Temperature		-55°C ~ 125°C
Contact Type		Female Socket
Fastening Type		Push-Pull
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Copper Alloy
Insulation Color		Black
Pitch - Mating		0.039" (1.00mm)
Contact Finish - Mating		Gold
Contact Finish - Post		Tin
Contact Finish Thickness - Post		157.5µin (4.00µm)
Contact Shape		Square
Contact Length - Post		0.047" (1.20mm)
Insulation Height		0.207" (5.25mm)
Insulation Material		Liquid Crystal Polymer (LCP)
Row Spacing - Mating		0.059" (1.50mm)
Number of Rows		2

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
