484290-E _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	484290-E
Manufacturer	TE Connectivity ERNI
Other Part Numbers	2684-484290-E-ND 2684-484290-E
Description	50-PIN, VERTICAL, SMT
Detailed Description	Connector Header Through Hole, Right Angle 50 position 0.039" (1.00mm)
Manufacturer Standard Lead Time	60 weeks

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		TE Connectivity ERNI
Series		MICROSPEED
Packaging		Box
Part Status		Active
Features		Pick and Place
Connector Type		Header
Mounting Type		Through Hole, Right Angle
Number of Positions		50
Number of Rows		2
Style		Board to Cable/Wire
Contact Type		Male Pin
Fastening Type		Push-Pull
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Insulation Color		Natural
Pitch - Mating		0.039" (1.00mm)
Contact Finish - Mating		Gold
Contact Finish - Post		Tin
Contact Finish Thickness - Post		157.5µin (4.00µm)
Contact Shape		Square
Insulation Height		0.543" (13.80mm)
Shrouding		Shrouded - 4 Wall
Row Spacing - Mating		0.059" (1.50mm)

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		Not Applicable
RoHS Status		ROHS3 Compliant

Can ship immediately.

QUANTITY

PACKAGING	QUANTITY	UNIT PRICE	EXT PRICE
Box	1	$15.97	$15.97
Total Amount: $15.97
