5962-9314002HXA

5962-9314002HXA

Part Number	5962-9314002HXA
Manufacturer	Broadcom
Other Part Numbers	5962-9314002HXA-ND
Description	OPTOISO 1.5KV PWR MOSFET 8DIP GW
Detailed Description	Optoisolator Power MOSFET 1500VDC 1 Channel 8-DIP Gull Wing
Manufacturer Standard Lead Time	20 weeks
Datasheet	Datasheet

Product Attributes

Category		Isolators Special Purpose Isolators
Manufacturer		Broadcom
Series
Packaging		Tube
Part Status		Active
Package / Case		8-SMD, Gull Wing
Mounting Type		Surface Mount
Type		Power MOSFET
Operating Temperature		-55°C ~ 125°C
Input Type		DC
Current - Output / Channel		1.6A
Voltage - Isolation		1500VDC
Supplier Device Package		8-DIP Gull Wing
Propagation Delay tpLH / tpHL (Max)		6ms, 0.25ms
Number of Channels		1
Current - DC Forward (If) (Max)		20 mA
Voltage - Forward (Vf) (Typ)		1.24 V

Documents & Media

RESOURCE TYPE		LINK
Datasheets		New LED 29/Aug/2012
Datasheets		Mosfet IC Vendor Update 28/Aug/2015

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.49.8000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS non-compliant
