714-144 _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	714-144
Manufacturer	WAGO
Other Part Numbers	2946-714-144-ND 0714-144 2943-714-144 714144 2943-714-144-ND 0714144 0714-0144 2946-714-144 7140144
Description	THT MALE HEADER; 0.8 X 0.8 MM SO
Detailed Description	14 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138" (3.50mm) Vertical Through Hole
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		WAGO
Series		MCSMINI SL
Packaging		Box
Part Status		Active
Color		Black
Mounting Type		Through Hole
Number of Positions		14
Pitch		0.138" (3.50mm)
Type		Header, Male Pins, Shrouded (4 Side)
Operating Temperature		-60°C ~ 100°C
Termination Style		Solder
Material Flammability Rating		UL94 V-0
Current - IEC		8A
Number of Levels		1
Positions Per Level		14
Contact Material		Electrolytic Copper
Header Orientation		Vertical
Housing Material		Polyphthalamide (PPA), Glass Filled
Contact Mating Finish		Tin
Contact Tail Length		0.134" (3.40mm)
Insulation Height		0.272" (6.91mm)
Current - UL		8 A
Voltage - IEC		320 V
Voltage - UL		150 V

RESOURCE TYPE		LINK
Datasheets		714-144

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
