745-207

Part Number
745-207
Manufacturer WAGO
Other Part Numbers
2946-745-207-ND
2943-745-207-ND
2946-745-207
745207
0745-0207
51142309
0745207
0745-207
2943-745-207
Description PCB TERMINAL BLOCK; 4 MM; PIN SP
Detailed Description 7 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.394" (10.00mm) Through Hole
Manufacturer Standard Lead Time 12 weeks

Product Attributes

Category
Manufacturer WAGO
Series
745
Packaging
Box
Part Status Active
Color Gray
Mounting Type Through Hole
Wire Gauge 12-28 AWG
Pitch 0.394" (10.00mm)
Operating Temperature -60°C ~ 105°C
Mating Orientation 45° (135°) Angle with Board
Positions Per Level 7
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Electrolytic Copper - Tin Plated
Clamp Material - Plating Steel - Nickel Plated
Wire Termination Screwless - Spring Cage, Tension Clamp
Current 20 A
Number of Levels 1
Voltage 300 V

Documents & Media

RESOURCE TYPE LINK

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8536.90.4000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
RoHS Status ROHS3 Compliant
