74LVQ00TTR

Part Number
74LVQ00TTR
Manufacturer STMicroelectronics
Other Part Numbers
74LVQ00TTR-ND
Description IC GATE NAND 4CH 2-INP 14TSSOP
Detailed Description NAND Gate IC 4 Channel 14-TSSOP
Datasheet Datasheet

Product Attributes

Category
Manufacturer STMicroelectronics
Series
74LVQ
Packaging
Tape & Reel (TR)
Part Status Obsolete
Package / Case 14-TSSOP (0.173", 4.40mm Width)
Mounting Type Surface Mount
Logic Type NAND Gate
Operating Temperature -55°C ~ 125°C
Voltage - Supply 2V ~ 3.6V
Current - Output High, Low 24mA, 24mA
Number of Inputs 2
Supplier Device Package 14-TSSOP
Input Logic Level - High 2V
Input Logic Level - Low 0.8V
Max Propagation Delay @ V, Max CL 8ns @ 3.3V, 50pF
Number of Circuits 4
Current - Quiescent (Max) 2 µA

Documents & Media

RESOURCE TYPE LINK
Datasheets 74LVQ00TTR

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8542.39.0001
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant

Obsolete

This product is no longer manufactured.
