78613/1C

Part Number
78613/1C
Manufacturer Murata Power Solutions
Other Part Numbers
811-3723-ND
78613/1C-ND
811-3723
Description PULSE XFMR 1CT:1 2MH
Detailed Description 2mH General Purpose Pulse Transformer 1CT:1 Through Hole
Manufacturer Standard Lead Time 14 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Murata Power Solutions
Series
786
Packaging
Tube
Part Status Active
Inductance 2mH
Size / Dimension 0.375" L x 0.354" W (9.52mm x 9.00mm)
Mounting Type Through Hole
Operating Temperature 0°C ~ 70°C
Transformer Type General Purpose
Turns Ratio - Primary:Secondary 1CT:1
ET (Volt-Time) 20VµS
Height - Seated (Max) 0.250" (6.35mm)

Documents & Media

RESOURCE TYPE LINK
Datasheets 78613/1C

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.31.2000
Moisture Sensitivity Level (MSL) Not Applicable
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant

In Stock: 90

Can ship immediately.
