78613/8JC-R

78613/8JC-R

Part Number	78613/8JC-R
Manufacturer	Murata Power Solutions
Other Part Numbers	78613/8JC-R-ND
Description	PULSE XFMR 1CT:1 980UH
Detailed Description	980µH General Purpose Pulse Transformer 1CT:1 Surface Mount
Manufacturer Standard Lead Time	10 weeks
Datasheet	Datasheet

Product Attributes

Category		Transformers Pulse Transformers
Manufacturer		Murata Power Solutions
Series		786J
Packaging		Tape & Reel (TR)
Part Status		Active
Inductance		980µH
Size / Dimension		0.375" L x 0.354" W (9.52mm x 9.00mm)
Mounting Type		Surface Mount
Operating Temperature		0°C ~ 70°C
Transformer Type		General Purpose
Turns Ratio - Primary:Secondary		1CT:1
ET (Volt-Time)		15VµS
Height - Seated (Max)		0.250" (6.35mm)

Documents & Media

RESOURCE TYPE		LINK
Datasheets		78613/8JC-R

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.31.2000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

Available To Order

QUANTITY

PACKAGING	QUANTITY	UNIT PRICE	EXT PRICE
{{ p.name }}	{{ numberFormat(p.buyQty) }}	{{ priceFormat(p.unitPrice) }}	{{ priceFormat(p.totalPrice) }}
Total Amount: {{ priceFormat(quotes.total) }} (including {{ priceFormat(quotes.fee) }} fee)

{{ package.name }}

QUANTITY	UNIT PRICE	EXT PRICE
{{ numberFormat(price.break_quantity) }}	{{ priceFormat(price.unit_price) }}	{{ priceFormat(price.break_quantity * price.unit_price) }}

Detailed pricing is currently unavailable.

Detailed packaging information is temporarily unavailable.
