9956410000 _ Wire to Board_Terminal Blocks_Connectors, Interconnects

Part Number	9956410000
Manufacturer	Weidmuller
Other Part Numbers	281-9956410000-ND 7940118817 995641-NDR 995641-ND 281-9956410000 9956410000-ND LU10.16/90/6/2 LU 10.16/06/90 4.5SN GY BX 995641
Description	TERM BLK 6P SIDE ENT 10.16MM PCB
Detailed Description	6 Position Wire to Board Terminal Block Horizontal with Board 0.400" (10.16mm) Through Hole
Manufacturer Standard Lead Time	27 weeks

Category		Connectors, Interconnects Terminal Blocks Wire to Board
Manufacturer		Weidmuller
Series		LU
Packaging		Bulk
Part Status		Active
Features		Interlocking (Side)
Color		Gray
Mounting Type		Through Hole
Wire Gauge		6-26 AWG
Pitch		0.400" (10.16mm)
Operating Temperature		-50°C ~ 100°C
Mating Orientation		Horizontal with Board
Positions Per Level		6
Housing Material		Polyamide (PA), Nylon
Contact Material - Plating		Electrolytic Copper - Tin Plated
Torque - Screw		1.2-1.5 Nm (10.6-13.3 Lb-In)
Screw Thread		M4
Wire Termination		Screw - Clamping Yoke, Tension Sleeve
Current		65 A
Number of Levels		1
Voltage		300 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
