Part Number | AM1SR-2403SJZ |
---|---|
Manufacturer | Aimtec |
Other Part Numbers | 5245-AM1SR-2403SJZ-ND 5245-AM1SR-2403SJZ 2721-AM1SR-2403SJZ 2721-AM1SR-2403SJZ-ND |
Description | 0.5W DC/DC Converter |
Detailed Description | Isolated Module DC DC Converter 1 Output 3.3V 200mA 22.8V - 25.2V Input |
Datasheet | Datasheet |
Category | ||
---|---|---|
Manufacturer | Aimtec | |
Series | ||
Packaging | Tube | |
Part Status | Active | |
Package / Case | 4-SIP Module | |
Size / Dimension | 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm) | |
Mounting Type | Through Hole | |
Type | Isolated Module | |
Operating Temperature | -40°C ~ 85°C (With Derating) | |
Applications | ITE (Commercial) | |
Voltage - Input (Max) | 25.2V | |
Efficiency | 68% | |
Current - Output (Max) | 200mA | |
Voltage - Input (Min) | 22.8V | |
Voltage - Output 1 | 3.3V | |
Power (Watts) | 660 mW | |
Number of Outputs | 1 | |
Voltage - Isolation | 1.5 kV | |
Standard Number | 62368-1 |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | AM1SR-2403SJZ |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
HTSUS | 8504.40.9580 | |
Moisture Sensitivity Level (MSL) | Not Applicable | |
REACH Status | REACH info available upon request | |
RoHS Status | ROHS3 Compliant |
QUANTITY | UNIT PRICE | EXT PRICE |
---|---|---|
1 | $2.30 | $2.30 |
5 | $2.27 | $11.35 |
10 | $2.23 | $22.30 |
25 | $2.17 | $54.25 |
50 | $2.10 | $105.00 |
100 | $2.04 | $204.00 |
250 | $1.97 | $492.50 |
500 | $1.84 | $920.00 |
