AM3A-1205DZ _ DC DC Converters_Power Supplies

Part Number	AM3A-1205DZ
Manufacturer	Aimtec
Other Part Numbers	2721-AM3A-1205DZ-ND 2721-AM3A-1205DZ 2374-AM3A-1205DZ
Description	DC DC CONVERTER +/-5V 3W
Detailed Description	Isolated Module DC DC Converter 2 Output 5V -5V 300mA, 300mA 4.5V - 18V Input
Datasheet	Datasheet

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		Aimtec
Series		AM3A-Z (3W)
Packaging		Tube
Part Status		Active
Package / Case		6-SIP Module, 5 Leads
Size / Dimension		0.69" L x 0.37" W x 0.48" H (17.5mm x 9.5mm x 12.2mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 76°C (With Derating)
Applications		ITE (Commercial)
Voltage - Input (Max)		18V
Efficiency		80%
Current - Output (Max)		300mA, 300mA
Voltage - Input (Min)		4.5V
Voltage - Output 1		5V
Voltage - Output 2		-5V
Power (Watts)		3 W
Number of Outputs		2
Voltage - Isolation		1.6 kV

RESOURCE TYPE		LINK
Datasheets		AM3A-1205DZ

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
