AM6T-0515D-NZ

AM6T-0515D-NZ

Part Number	AM6T-0515D-NZ
Manufacturer	Aimtec
Other Part Numbers	2721-AM6T-0515D-NZ-ND 2721-AM6T-0515D-NZ
Description	DC/DC Converter -15V 6W
Detailed Description	Isolated Module DC DC Converter 2 Output 15V -15V 200mA, 200mA 4.5V - 9V Input
Datasheet	Datasheet

Product Attributes

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		Aimtec
Series		AM6T-NZ
Packaging		Tube
Part Status		Active
Package / Case		24-DIP Module
Size / Dimension		1.26" L x 0.79" W x 0.42" H (32.0mm x 20.0mm x 10.8mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 85°C (With Derating)
Voltage - Input (Max)		9V
Efficiency		84%
Current - Output (Max)		200mA, 200mA
Voltage - Input (Min)		4.5V
Voltage - Output 1		15V
Voltage - Output 2		-15V
Number of Outputs		2
Standard Number		60950-1

Documents & Media

RESOURCE TYPE		LINK
Datasheets		AM6T-0515D-NZ

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
HTSUS		8504.40.9580
RoHS Status		RoHS Compliant
