AMM-2742-T-WP-R _ Microphones_Audio Products

Part Number	AMM-2742-T-WP-R
Manufacturer	PUI Audio, Inc.
Other Part Numbers	668-AMM-2742-T-WP-RTR-ND 668-AMM-2742-T-WP-RCT-ND 668-AMM-2742-T-WP-RCT 668-AMM-2742-T-WP-RTR
Description	MIC MEMS ANALOG OMNI -42DB
Detailed Description	20 Hz ~ 20 kHz Analog Microphone MEMS (Silicon) 1.6 V ~ 3.6 V Omnidirectional (-42dB ±1dB) Solder Pads
Manufacturer Standard Lead Time	17 weeks

Category		Audio Products Microphones
Manufacturer		PUI Audio, Inc.
Series
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Output Type		Analog
Size / Dimension		0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity		-42dB ±1dB
Shape		Rectangular
Type		MEMS (Silicon)
S/N Ratio		59dB
Termination		Solder Pads
Direction		Omnidirectional
Ratings		IP57 - Dust Protected, Waterproof
Port Location		Top
Height (Max)		0.039" (1.00mm)
Voltage - Rated		2 V
Impedance		300 Ohms
Current - Supply		200 µA
Voltage Range		1.6 V ~ 3.6 V
Frequency Range		20 Hz ~ 20 kHz

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
California Prop 65		California Prop 65 Information
ECCN		EAR99
HTSUS		8518.10.8030
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
