AWVF00303010150M00

Part Number
AWVF00303010150M00
Manufacturer Pulse Larsen Antenna
Other Part Numbers
553-AWVF00303010150M00TR-ND
553-AWVF00303010150M00TR
Description INDUCTOR POWER
Detailed Description 15 µH Shielded Inductor 550 mA 625mOhm 1212 (3030 Metric)
Manufacturer Standard Lead Time 13 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Pulse Larsen Antenna
Series
AWVF
Packaging
Tape & Reel (TR)
Part Status Active
Tolerance ±20%
Package / Case 1212 (3030 Metric)
Size / Dimension 0.118" L x 0.118" W (3.00mm x 3.00mm)
Mounting Type Surface Mount
Shielding Shielded
Operating Temperature -40°C ~ 125°C
DC Resistance (DCR) 625mOhm
Ratings AEC-Q200
Current - Saturation (Isat) 560mA
Material - Core Ferrite
Inductance Frequency - Test 1 MHz
Supplier Device Package 1212
Height - Seated (Max) 0.040" (1.02mm)
Inductance 15 µH
Current Rating (Amps) 550 mA

Documents & Media

RESOURCE TYPE LINK
Datasheets AWVF00303010150M00
Datasheets Pulse Larson REACH

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.8000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant
