BZT52C22W

BZT52C22W

Part Number	BZT52C22W
Manufacturer	YAGEO
Other Part Numbers	13-BZT52C22WTR-ND 13-BZT52C22WCT-ND 13-BZT52C22WDKR-ND 13-BZT52C22WCT 13-BZT52C22WTR 13-BZT52C22WDKR
Description	ZENER SOD-123 22V 500MW
Detailed Description	Zener Diode 22 V 500 mW ±5.68% Surface Mount SOD-123
Manufacturer Standard Lead Time	25 weeks
Datasheet	Datasheet

Product Attributes

Category		Discrete Semiconductor Products Diodes Zener Single Zener Diodes
Manufacturer		YAGEO
Series		BZT52CXXW
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Tolerance		±5.68%
Package / Case		SOD-123F
Mounting Type		Surface Mount
Operating Temperature		150°C (TJ)
Voltage - Zener (Nom) (Vz)		22 V
Impedance (Max) (Zzt)		55 Ohms
Supplier Device Package		SOD-123
Power - Max		500 mW
Voltage - Forward (Vf) (Max) @ If		900 mV @ 10 mA
Current - Reverse Leakage @ Vr		100 nA @ 15.4 V
