CD4009UBE

CD4009UBE

Part Number	CD4009UBE
Manufacturer	Texas Instruments
Other Part Numbers	296-2030-5-ND -296-2030-5 -296-2030-5-ND -CD4009UBEE4-NDR -CD4009UBEE4 296-2030-5 2166-CD4009UBE-296 2156-CD4009UBE -CD4009UBE-NDR
Description	IC INVERTER 6CH 1-INP 16DIP
Detailed Description	Inverter IC 6 Channel 16-PDIP
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Product Attributes

Category		Integrated Circuits (ICs) Logic Gates and Inverters
Manufacturer		Texas Instruments
Series		4000B
Packaging		Tube
Part Status		Active
Package / Case		16-DIP (0.300", 7.62mm)
Mounting Type		Through Hole
Logic Type		Inverter
Operating Temperature		-55°C ~ 125°C
Voltage - Supply		3V ~ 18V
Current - Output High, Low		1.5mA, 24mA
Number of Inputs		1
Supplier Device Package		16-PDIP
Input Logic Level - High		4V ~ 12.5V
Input Logic Level - Low		1V ~ 2.5V
Max Propagation Delay @ V, Max CL		60ns @ 15V, 50pF
Number of Circuits		6
Current - Quiescent (Max)		4 µA
