Part Number | CI1106M1HR0-NH |
---|---|
Manufacturer | CviLux |
Other Part Numbers | 2987-CI1106M1HR0-NHTR-ND 2987-CI1106M1HR0-NHCT-ND 2987-CI1106M1HR0-NHCT 2987-CI1106M1HR0-NHTR |
Description | 6POS 1.00MM(.039) SINGLE ROW RIG |
Detailed Description | Connector Header Surface Mount, Right Angle 6 position 0.039" (1.00mm) |
Manufacturer Standard Lead Time | 13 weeks |
Datasheet | Datasheet |
Category | ||
---|---|---|
Manufacturer | CviLux | |
Series | CI11 | |
Packaging | Tape & Reel (TR) Cut Tape (CT) | |
Part Status | Active | |
Features | Solder Retention | |
Connector Type | Header | |
Voltage Rating | 50VAC | |
Current Rating (Amps) | 1A (AC/DC) | |
Mounting Type | Surface Mount, Right Angle | |
Number of Positions | 6 | |
Number of Rows | 1 | |
Style | Board to Cable/Wire | |
Operating Temperature | -25°C ~ 85°C | |
Contact Type | Male Pin | |
Fastening Type | Detent Lock | |
Number of Positions Loaded | All | |
Termination | Solder | |
Material Flammability Rating | UL94 V-0 | |
Contact Material | Phosphor Bronze | |
Insulation Color | Natural | |
Pitch - Mating | 0.039" (1.00mm) | |
Contact Finish - Mating | Tin | |
Contact Finish Thickness - Mating | 100.0µin (2.54µm) | |
Contact Finish - Post | Tin | |
Contact Finish Thickness - Post | 100.0µin (2.54µm) | |
Contact Shape | Rectangular | |
Insulation Height | 0.116" (2.95mm) | |
Shrouding | Shrouded - 4 Wall | |
Insulation Material | Polyamide (PA6T), Nylon 6T, Glass Filled, Halogen Free | |
Contact Length - Mating | 0.069" (1.75mm) |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | CI1106M1HR0-NH |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8536.69.4040 | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
REACH Status | REACH Unaffected | |
RoHS Status | ROHS3 Compliant |
QUANTITY | UNIT PRICE | EXT PRICE |
---|---|---|
1,500 | $0.09 | $135.00 |
3,000 | $0.09 | $270.00 |
7,500 | $0.09 | $675.00 |
10,500 | $0.08 | $840.00 |
15,000 | $0.07 | $1,050.00 |
37,500 | $0.07 | $2,625.00 |
75,000 | $0.07 | $5,250.00 |
QUANTITY | UNIT PRICE | EXT PRICE |
---|---|---|
1 | $0.21 | $0.21 |
10 | $0.18 | $1.80 |
100 | $0.14 | $14.00 |
500 | $0.12 | $60.00 |
