CTDS3308F-2R2M

Part Number
CTDS3308F-2R2M
Manufacturer Central Technologies
Other Part Numbers
4161-CTDS3308F-2R2M-ND
4161-CTDS3308F-2R2M
Description 2.2UH SMD SHIELDED POWR INDUCTOR
Detailed Description 2.2 µH Shielded Inductor 3.5 A 45mOhm Max Nonstandard
Datasheet Datasheet

Product Attributes

Category
Manufacturer Central Technologies
Series
CTDS3308F
Packaging
Tape & Reel (TR)
Part Status Active
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.500" L x 0.398" W (12.70mm x 10.10mm)
Mounting Type Surface Mount
Shielding Shielded
Operating Temperature -40°C ~ 125°C
DC Resistance (DCR) 45mOhm Max
Q @ Freq 30 @ 100kHz
Frequency - Self Resonant 90MHz
Inductance Frequency - Test 100 kHz
Height - Seated (Max) 0.118" (3.00mm)
Inductance 2.2 µH
Current Rating (Amps) 3.5 A

Documents & Media

RESOURCE TYPE LINK
Datasheets CTDS3308F-2R2M

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
Moisture Sensitivity Level (MSL) Vendor Undefined
REACH Status REACH info available upon request
RoHS Status ROHS3 Compliant
