CTSLF1045TF-221M

Part Number
CTSLF1045TF-221M
Manufacturer Central Technologies
Other Part Numbers
4161-CTSLF1045TF-221M-ND
4161-CTSLF1045TF-221M
Description 220UH SMD SHLDED POWER INDUCTOR
Detailed Description 220 µH Shielded Inductor 700 mA 470mOhm Nonstandard

Product Attributes

Category
Manufacturer Central Technologies
Series
CTSLF1045TF
Packaging
Tape & Reel (TR)
Part Status Active
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.398" L x 0.398" W (10.10mm x 10.10mm)
Mounting Type Surface Mount
Shielding Shielded
Operating Temperature -20°C ~ 85°C
DC Resistance (DCR) 470mOhm
Current - Saturation (Isat) 650mA
Inductance Frequency - Test 1 kHz
Height - Seated (Max) 0.189" (4.80mm)
Inductance 220 µH
Current Rating (Amps) 700 mA

Documents & Media

RESOURCE TYPE LINK

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
Moisture Sensitivity Level (MSL) Vendor Undefined
REACH Status REACH info available upon request
RoHS Status ROHS3 Compliant
