G3SD-Z01P-PD-US DC12

G3SD-Z01P-PD-US DC12

Part Number	G3SD-Z01P-PD-US DC12
Manufacturer	Omron Automation
Other Part Numbers	Z8379-ND G3SD1022H G3SDZ01PPDUS12DC G3SD-Z01P-PD-USDC12 G3SD-Z01P-PD-USDC12-ND Z8379 G3SDZ01PPDUSDC12
Description	SSR RELAY SPST-NO 1.1A 3-26V
Detailed Description	Solid State SPST-NO (1 Form A) Module
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Product Attributes

Category		Relays Solid State Relays (SSR)
Manufacturer		Omron Automation
Series		G3SD
Packaging		Bulk
Part Status		Active
Package / Case		Module
Output Type		DC
Mounting Type		Through Hole
Voltage - Input		9.6 ~ 14.4VDC
Circuit		SPST-NO (1 Form A)
Termination Style		PC Pin
Load Current		1.1 A
Voltage - Load		3 V ~ 26 V

Documents & Media

RESOURCE TYPE		LINK
Datasheets		G3SD-Z01P-PD-US DC12
Datasheets		SSR Design Considerations

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.41.0030
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Affected
RoHS Status		ROHS3 Compliant

In Stock: 3

Can ship immediately.
