IP3253CZ16-8-TTL,1 _ EMI/RFI Filters (LC, RC Networks)_Filters

Part Number	IP3253CZ16-8-TTL,1
Manufacturer	NXP Semiconductors
Other Part Numbers	2156-IP3253CZ16-8-TTL1-ND 2156-IP3253CZ16-8-TTL1 NEXNXPIP3253CZ16-8-TTL,1
Description	CONSUMER CIRCUIT
Detailed Description	LC (Pi) EMI Filter 3rd Order Low Pass 8 Channel L = 18nH (Total), C = 25pF (Total) 30 mA 16-UFDFN Exposed Pad

Category		Filters EMI/RFI Filters (LC, RC Networks)
Manufacturer		NXP Semiconductors
Series
Packaging		Bulk
Part Status		Active
Package / Case		16-UFDFN Exposed Pad
Size / Dimension		0.130" L x 0.053" W (3.30mm x 1.35mm)
Mounting Type		Surface Mount
Type		Low Pass
Operating Temperature		-40°C ~ 85°C
Values		L = 18nH (Total), C = 25pF (Total)
Height		0.022" (0.55mm)
Attenuation Value		30dB @ 1GHz ~ 4GHz
Filter Order		3rd
Applications		GSM, LAN, PCS, WAN
Technology		LC (Pi)
Center / Cutoff Frequency		175MHz (Cutoff)
Resistance - Channel (Ohms)		8
ESD Protection		Yes
Number of Channels		8
Current		30 mA

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8542.39.0001
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
