IRFAC30 _ Single FETs, MOSFETs_FETs, MOSFETs_Transistors_Discrete Semiconductor Products

Part Number	IRFAC30
Manufacturer	International Rectifier
Other Part Numbers	2156-IRFAC30-ND 2156-IRFAC30 IRFIRFIRFAC30
Description	N-CHANNEL HERMETIC MOS HEXFET
Detailed Description	N-Channel 600 V 3.6A (Tc) 75W (Tc) Through Hole TO-204AA (TO-3)

Category		Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs
Manufacturer		International Rectifier
Series		HEXFET®
Packaging		Bulk
Part Status		Active
Package / Case		TO-204AA, TO-3
Mounting Type		Through Hole
Operating Temperature		-55°C ~ 150°C (TJ)
Technology		MOSFET (Metal Oxide)
FET Type		N-Channel
Current - Continuous Drain (Id) @ 25°C		3.6A (Tc)
Rds On (Max) @ Id, Vgs		2.5Ohm @ 3.6A, 10V
Power Dissipation (Max)		75W (Tc)
Vgs(th) (Max) @ Id		4V @ 250µA
Supplier Device Package		TO-204AA (TO-3)
Drive Voltage (Max Rds On, Min Rds On)		10V
Vgs (Max)		±20V
Drain to Source Voltage (Vdss)		600 V
Gate Charge (Qg) (Max) @ Vgs		38 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds		630 pF @ 25 V

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.29.0095
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		Vendor Undefined
RoHS Status		RoHS non-compliant
