LY1F-DC12 _ Power Relays, Over 2 Amps_Relays

Part Number	LY1F-DC12
Manufacturer	Omron Automation
Other Part Numbers	Z193-ND Z193 LY1FDC12
Description	RELAY GEN PURPOSE SPDT 15A 12V
Detailed Description	General Purpose Relay SPDT (1 Form C) 12VDC Coil Chassis Mount
Manufacturer Standard Lead Time	9 weeks
Datasheet	Datasheet

Category		Relays Power Relays, Over 2 Amps
Manufacturer		Omron Automation
Series		LY
Packaging		Bulk
Part Status		Active
Mounting Type		Chassis Mount
Coil Voltage		12VDC
Operating Temperature		-25°C ~ 55°C
Termination Style		Plug In
Approval Agency		CE, CSA, TUV, UR
Relay Type		General Purpose
Coil Current		75 mA
Coil Type		Non Latching
Contact Material		Silver Alloy
Contact Form		SPDT (1 Form C)
Contact Rating (Current)		15 A
Switching Voltage		250VAC, 125VDC - Max
Must Release Voltage		1.2 VDC
Must Operate Voltage		9.6 VDC
Operate Time		25 ms
Release Time		25 ms
Coil Resistance		160 Ohms
Load - Max Switching		3750VA, 1875W

RESOURCE TYPE		LINK
Datasheets		LY1F-DC12
Datasheets		Multiple Devices Nameplate May/2015
Datasheets		LY1F, LY2F Bottom
Datasheets		LY1F, LY2F Side

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.41.0050
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
