MOCD207R1M _ Transistor, Photovoltaic Output Optoisolators_Optoisolators_Isolators

Part Number	MOCD207R1M
Manufacturer	Sanyo Semiconductor/onsemi
Other Part Numbers	MOCD207R1MTR-ND MOCD207R1MCT-ND MOCD207R1MDKR-ND MOCD207R1M-ND MOCD207R1MTR MOCD207R1M-NDR MOCD207R1MCT MOCD207R1MDKR
Description	OPTOISO 2.5KV 2CH TRANS 8SOIC
Detailed Description	Optoisolator Transistor Output 2500Vrms 2 Channel 8-SOIC
Datasheet	Datasheet

Category		Isolators Optoisolators Transistor, Photovoltaic Output Optoisolators
Manufacturer		Sanyo Semiconductor/onsemi
Series
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Obsolete
Package / Case		8-SOIC (0.154", 3.90mm Width)
Output Type		Transistor
Mounting Type		Surface Mount
Operating Temperature		-40°C ~ 100°C
Voltage - Forward (Vf) (Typ)		1.25V
Input Type		DC
Current - Output / Channel		150mA
Voltage - Isolation		2500Vrms
Current Transfer Ratio (Min)		100% @ 10mA
Vce Saturation (Max)		400mV
Current Transfer Ratio (Max)		200% @ 10mA
Supplier Device Package		8-SOIC
Voltage - Output (Max)		70V
Turn On / Turn Off Time (Typ)		3µs, 2.8µs
Rise / Fall Time (Typ)		1.6µs, 2.2µs
Number of Channels		2
Current - DC Forward (If) (Max)		60 mA

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.49.8000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected

This product is no longer manufactured.
