NC7SV32P5X

NC7SV32P5X

Part Number	NC7SV32P5X
Manufacturer	Fairchild Semiconductor
Other Part Numbers	2156-NC7SV32P5X-ND FAIFSCNC7SV32P5X 2156-NC7SV32P5X
Description	IC GATE OR 1CH 2-INP SC70-5
Detailed Description	OR Gate IC 1 Channel SC-70-5

Product Attributes

Category		Integrated Circuits (ICs) Logic Gates and Inverters
Manufacturer		Fairchild Semiconductor
Series		7SV
Packaging		Bulk
Part Status		Active
Package / Case		5-TSSOP, SC-70-5, SOT-353
Mounting Type		Surface Mount
Logic Type		OR Gate
Operating Temperature		-40°C ~ 85°C
Voltage - Supply		0.9V ~ 3.6V
Current - Output High, Low		24mA, 24mA
Number of Inputs		2
Supplier Device Package		SC-70-5
Input Logic Level - High		1.6V ~ 2V
Input Logic Level - Low		0.7V ~ 0.8V
Max Propagation Delay @ V, Max CL		3.3ns @ 3V, 30pF
Number of Circuits		1
Current - Quiescent (Max)		900 nA
