PA4300.683NLT

Part Number
PA4300.683NLT
Manufacturer Pulse Larsen Antenna
Other Part Numbers
553-2437-2-ND
553-2437-1-ND
553-2437-6-ND
553-2437-6
-PA4300.683NLT
2266-PA4300.683NLTTR
553-2437-1
553-2437-2
Description FIXED IND 68UH 505MA 364MOHM SMD
Detailed Description 68 µH Shielded Drum Core, Wirewound Inductor 505 mA 364mOhm Max Nonstandard
Manufacturer Standard Lead Time 11 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Pulse Larsen Antenna
Series
PA4300.XXXNLT
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Part Status Active
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.240" L x 0.240" W (6.10mm x 6.10mm)
Mounting Type Surface Mount
Shielding Shielded
Type Drum Core, Wirewound
Operating Temperature -40°C ~ 125°C
DC Resistance (DCR) 364mOhm Max
Material - Core Ferrite
Inductance Frequency - Test 1 kHz
Height - Seated (Max) 0.118" (3.00mm)
Inductance 68 µH
Current Rating (Amps) 505 mA

Documents & Media

RESOURCE TYPE LINK
Datasheets Pulse Larson REACH

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.4000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant
