PBC22DABN _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	PBC22DABN
Manufacturer	Sullins Connector Solutions
Other Part Numbers	S2021E-22-ND S2021E-22
Description	CONN HEADER VERT 44POS 2.54MM
Detailed Description	Connector Header Through Hole 44 position 0.100" (2.54mm)
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		Sullins Connector Solutions
Series
Packaging		Bulk
Part Status		Active
Connector Type		Header, Breakaway
Current Rating (Amps)		3A
Mounting Type		Through Hole
Number of Positions		44
Number of Rows		2
Style		Board to Board or Cable
Operating Temperature		-65°C ~ 125°C
Contact Type		Male Pin
Fastening Type		Push-Pull
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Phosphor Bronze
Insulation Color		Black
Pitch - Mating		0.100" (2.54mm)
Contact Finish - Mating		Gold
Contact Finish Thickness - Mating		10.0µin (0.25µm)
Contact Finish - Post		Tin
Contact Finish Thickness - Post		100.0µin (2.54µm)
Contact Shape		Square
Contact Length - Post		0.230" (5.84mm)
Insulation Height		0.100" (2.54mm)
Shrouding		Unshrouded
Overall Contact Length		0.560" (14.22mm)
Insulation Material		Polybutylene Terephthalate (PBT)
Row Spacing - Mating		0.100" (2.54mm)
Contact Length - Mating		0.230" (5.84mm)

RESOURCE TYPE		LINK
Datasheets		PBC22DABN
Datasheets		Sullins Connector Solutions REACH
Datasheets		Sullins Connector Solutions RoHS Cert
Datasheets		xxCxxDxxN Drawing

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

PACKAGING	QUANTITY	UNIT PRICE	EXT PRICE
Bulk	1	$2.58	$2.58
Total Amount: $2.58
