PRG21BB220MB1RK

PRG21BB220MB1RK

Part Number	PRG21BB220MB1RK
Manufacturer	TOKO / Murata
Other Part Numbers	490-3989-2-ND 490-3989-1-ND 490-3989-6-ND 490-3989-1 490-3989-2 490-3989-6
Description	PTC RESET FUSE 20V 44MA 0805
Detailed Description	Ceramic PTC Resettable Fuse 20V 44 mA Ih Surface Mount 0805 (2012 Metric)
Manufacturer Standard Lead Time	21 weeks
Datasheet	Datasheet

Product Attributes

Category		Circuit Protection PTC Resettable Fuses
Manufacturer		TOKO / Murata
Series		POSISTOR®, PRG
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Package / Case		0805 (2012 Metric)
Size / Dimension		0.079" L x 0.049" W (2.00mm x 1.25mm)
Mounting Type		Surface Mount
Type		Ceramic
Operating Temperature		-20°C ~ 60°C
Approval Agency		UL
Current - Hold (Ih) (Max)		44 mA
Current - Trip (It)		91 mA
Voltage - Max		20V
Thickness (Max)		0.057" (1.45mm)
Current - Max		1.1 A
Resistance - 25°C (Typ)		22 Ohms

Documents & Media

RESOURCE TYPE		LINK
Datasheets		POSISTOR® Series Catalog
Datasheets		Mult Series Location 20/Jun/2022
Datasheets		PRG21_RA,RK Series Footprint
Datasheets		PRG21_RA,RK Series Top
Datasheets		PRG21_RK Series Side

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8533.40.8070
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

In Stock: 5603

Can ship immediately.
