Part Number | RDH4028B5 |
---|---|
Manufacturer | Pelonis Technologies |
Other Part Numbers | 3611-RDH4028B5-ND 3611-RDH4028B5 |
Description | FAN AXIAL 40X28MM BALL 5VDC WIRE |
Detailed Description | Fan Tubeaxial 5VDC Square - 40mm L x 40mm H Ball 9.4 CFM (0.26m³/min) 2 Wire Leads |
Category | ||
---|---|---|
Manufacturer | Pelonis Technologies | |
Series | hiFLOW | |
Packaging | Bulk | |
Part Status | Active | |
Features | Auto Restart, Locked Rotor Protection, Polarity Protection | |
Voltage - Rated | 5VDC | |
Size / Dimension | Square - 40mm L x 40mm H | |
Bearing Type | Ball | |
RPM | 7500 RPM | |
Air Flow | 9.4 CFM (0.26m³/min) | |
Width | 28.00mm | |
Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) | |
Termination | 2 Wire Leads | |
Approval Agency | CE, cUL, UL | |
Fan Type | Tubeaxial | |
Noise | 32.0dB(A) | |
Static Pressure | 0.230 in H2O (57.3 Pa) | |
Power (Watts) | 1.75 W |
RESOURCE TYPE | LINK |
---|
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8414.59.6590 | |
Moisture Sensitivity Level (MSL) | Not Applicable | |
REACH Status | Vendor Undefined | |
RoHS Status | ROHS3 Compliant |
QUANTITY | UNIT PRICE | EXT PRICE |
---|---|---|
1 | $12.38 | $12.38 |
10 | $11.55 | $115.50 |
25 | $10.82 | $270.50 |
50 | $9.94 | $497.00 |
100 | $9.34 | $934.00 |
250 | $8.63 | $2,157.50 |
500 | $7.17 | $3,585.00 |
