RLY30000

Part Number
RLY30000
Manufacturer Red Lion
Other Part Numbers
RLC609-ND
RLY30000-ND
RLC609
Description RELAY GEN PURPOSE DPDT 10A 115V
Detailed Description General Purpose Relay DPDT (2 Form C) 115VAC Coil Socketable

Product Attributes

Category
Manufacturer Red Lion
Series
RLY3
Packaging
Bulk
Part Status Obsolete
Mounting Type Socketable
Coil Voltage 115VAC
Operating Temperature -45°C ~ 60°C
Termination Style Plug In, 8 Pin (Octal)
Relay Type General Purpose
Coil Current 51.1 mA
Coil Type Non Latching
Contact Form DPDT (2 Form C)
Contact Rating (Current) 10 A
Switching Voltage 115VAC - Max
Operate Time 30 ms
Release Time 30 ms
Load - Max Switching 1150VA

Documents & Media

RESOURCE TYPE LINK

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8536.49.0075
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant

Obsolete

This product is no longer manufactured.
