RTTC8702X _ Audio Connectors_Barrel Connectors_Connectors, Interconnects

Part Number	RTTC8702X
Manufacturer	Switchcraft / Conxall
Other Part Numbers	SC1998-ND RTTC8702-NDL RTTC8702-ND RTTC8702X-ND Q1196195 Q1356710 SC1998 RTTC8702
Description	CONN JACK TWIN STEREO 4.39MM R/A
Detailed Description	4.39mm (0.173") Phone Jack, Twin Stereo (3 Conductor, TRS) Connector Solder
Datasheet	Datasheet

Category		Connectors, Interconnects Barrel Connectors Audio Connectors
Manufacturer		Switchcraft / Conxall
Series		RTTC
Packaging		Bulk
Part Status		Active
Features		Cover
Connector Type		Phone Jack, Twin
Gender		Female
Mounting Type		Through Hole, Right Angle
Shielding		Unshielded
Operating Temperature		-55°C ~ 85°C
Number of Positions/Contacts		2 Sets of 3 Conductors, 10 Contacts
Internal Switch(s)		2 Sets of Two Switches
Signal Lines		Stereo (3 Conductor, TRS)
Termination		Solder
Includes		2 pcs - 1 Connector, 1 Cover
Contact Material		Copper Alloy
Housing Material		Thermoplastic
Body Color		Black
Contact Material - Plating		Gold
Insulation Color		Black
Actual Diameter		0.177" (4.48mm)
Industry Recognized Mating Diameter		4.39mm (0.173")

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
