S1C17W22F101100

Part Number
S1C17W22F101100
Manufacturer Epson Electronics America Inc-Semiconductor Div
Other Part Numbers
S1C17W22F101100-ND
Description IC MCU 16BIT 64KB FLASH 128TQFP
Detailed Description S1C17 - Microcontroller IC 16-Bit 4.2MHz 64KB (64K x 8) FLASH 128-TQFP (14x14)
Manufacturer Standard Lead Time 38 weeks

Product Attributes

Category
Manufacturer Epson Electronics America Inc-Semiconductor Div
Series
Packaging
Tray
Part Status Active
Package / Case 128-TQFP
Mounting Type Surface Mount
Speed 4.2MHz
Program Memory Size 64KB (64K x 8)
RAM Size 4K x 8
Operating Temperature -40°C ~ 85°C (TA)
Oscillator Type Internal
Program Memory Type FLASH
Core Processor S1C17
Core Size 16-Bit
Voltage - Supply (Vcc/Vdd) 1.2V ~ 3.6V
Connectivity I2C, IrDA, SPI, UART/USART
Peripherals LCD, PWM, RFC, WDT
Supplier Device Package 128-TQFP (14x14)
Number of I/O 41
DigiKey Programmable Not Verified

Documents & Media

RESOURCE TYPE LINK
Datasheets S1C17W22F101100
Datasheets S1C17W22,23 Manual

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8542.31.0001
Moisture Sensitivity Level (MSL) 3 (168 Hours)
RoHS Status RoHS Compliant
